AQA 22 Alu

There are many innovation in the design of new AQA 22 aluminum rigid inflatable boat: This is the FIRST RIB with structural aluminum bow , fully walkable that hides the electric windlass inside; big-section tubes in a single stepped hull with high deadrise; double sundress area - at the bow and at the stern, double stern seat foldable, lunch area with table . All of it in a hull created for extreme conditions, built of marine grade aluminum 5083 with heavy-duty stiffening systems .

Read More
AQA 22 Alu



The boat is unsinkable, due to its top-resilient material. The hull is completely and securely welded with joint frames and becomes a single-piece object. Wide and protective consolle provided for demanding users also offers protection from wind and sun, with the possibility to be entirely closed ; the rib has a comfortable port side aisle, big stern platforms with built-in ladder. Self bailing, unsinkable, with 6 watertight compartments, it can face any condition in safety, but it can also be a comfortable holiday machine with his sundress surface and wide seats. It has a plastic gasoline tank, 190 litres, that allows up to 200 miles crusing. The speed is almost 50 knots with a 225 hp outboards, but 150 hp is enough for sport performances. The design project of the rib has been done with CAD 3d software, checked also with RhinoHYD advanced software for stability and hydrostatic calculations and Scan&Solve FEA simulator for the structural analysis; the hull is built with MIG weldings that complies ISO requirements , starting from plate nesting and cnc-laser cutting. The AQA 22 Rib is more than polyvalent: it is always on top for any use. Fine costruction by AQA Aluminum boats..

Technical specs:

    Lenght LOA 7.30 m
  • Lenght hull 6.70 m
  • Beam 2.82 m
  • Width deflated 2.24 m
  • Tubes hypalon neoprene
  • Compartments 6
  • Diameter 0.62 m
  • Hull weight 750 kg
  • Power FB from 130 to 225 hp
  • Recommended power 150 hp
  • Gasoline tank 195 l
  • Fresh water tank 50 l
  • Persons max 12
  • Hull Single Step
  • Deadrise medium 30°
  • CE design category B/C
